Application in Oil and Gas
-
TUBEPLUS Capillary and Encapsulated Tubes are engineered for chemical injection, control lines, and monitoring systems, ensuring long-term reliability in corrosive and high-pressure environments.
| Item | Description |
| Product Type | Capillary Tube / Encapsulated Tube |
| Standards | ASTM A269 / ASTM A789 |
| Materials | 316L, Duplex 2205, Incoloy 825 |
| OD Range | 1/8″ – 1/2″ |
| Wall Thickness | 0.028″ – 0.083″ |
| Encapsulation | HDPE / Stainless Steel |
| Applications | Chemical Injection, Downhole Monitoring |
| Certification | MTC, Pressure Test |
| Year | Project | Country | End User | Material | Products | Qty (KGS) |
| 2024 | FPSO Chemical Injection | Brazil | Petrobras | Duplex 2205 | Encapsulated Tube | 92000 |
| 2023 | Offshore Gas Field | Norway | Equinor | Incoloy 825 | Capillary Tube | 38000 |
| 2022 | Deepwater Injection Line | USA | Chevron | 316L | Capillary Tube | 44000 |
| Inspection Item | Standard / Method |
| Chemical Composition | PMI / Spectrometer Test |
| Pressure Resistance | Hydrostatic / Pneumatic Test |
| Eddy Current Test | ASTM A269 |
| Encapsulation Integrity | Sheath Thickness & Adhesion Check |
| Dimensional Accuracy | OD / ID / Wall Thickness Control |
| Surface Finish | Visual Inspection |
| Certification | EN 10204 3.1 / MTC |
