Alloy 601, UNS N06601
Alloy 601 ( UNS N06601 ) Summary A nickel-chromium alloy with an addition of aluminum for outstanding resistance to oxidation and other forms of high-temperature corrosion. It also has high mechanical properties at elevated temperatures. Used for industrial furnaces;heat treating equipment such as baskets,muffles,and retorts;petrochemical and other process equipment;and gas-turbine components. Standard Product Forms Pipe,tube,sheet,strip,plate,round […]
Alloy 600, UNS N06600
Alloy 600 (UNS N06600) Summary A nickel-chromium alloy with good oxidation resistance at high temperatures and resistance to chloride-ion stress-corrosion cracking,corrosion by high-purity water,and caustic corrosion. Used for furnace components,in chemical and food processing,in nuclear engineering,and for sparking electrodes. Standard Product Forms Pipe,tube,sheet,strip,plate,round bar,flat bar,forging stock,hexagon and wire. Chemical Composition Wt,% Min Max. Min. Max. […]
Square
Single Core Line Square Shape Hydraulic Control Line Shape Core Line Size(Height*width) Square 1*1/8”Line 0.250”x0.250”(6.35 mmx6.35mm) 1*1/4”Line 0.433”x0.250”(11.0 mmx11.0mm) 1*3/8”Line 0.535”x0.535”(13.6mmx13.6mm) 1*1/2”Line 0.660”x0.660”(16.8 mmx16.8 mm)
Round
Single Core Line Round Shape Hydraulic Control Line &Flat Pack Shape Core Line Size Round 1*1/8”Line 0.250”Diameter(6.35 mm 1*1/4”Line 0.410”Diameter(10.4mm) 1*3/8”Line 0.535”Diameter(13.6mm) 1*1/2”Line 0.660”Diameter(16.8mm)
Rectangle
Two-core Lines Rectangle Shape Hydraulic Control Line&Flat Pack Shape Core Line Size(Height*width) Rectangle 2*1/4″Line 0.433″x0.866″(11.0mmx22.0mm) 2*1/4″Line+7.5mm Wire Rope 0.472″×1.024″(13.0mmx26.0mm) 2*3/8″Line 0.512″×1.024″(16.0 mmx30.0mm) 2*1/2″Line 0.472″x1.024″(12.0 mmx26.0mm)
Inconel 625
PRODUCT STANDARD AND SIZE ASTM B444,Incoloy 625,UNS NO6625 Size OD Tolerance OD Tolerance WT 1/8″≤OD<3/16″(3.18mm≤OD≤4.76mm) +0.003″/-0 ±10% 3/16″≤OD<1/2″(4.76≤OD<12.7mm) ±0.004″(±0.10 mm)/-0 ±10% 1/2″≤OD≤1″(12.7≤OD≤25.4 mm) ±0.005″(±0.13 mm)/-0 ±10% CHEMICAL COMPOSITION C Mn P S Si Cr Ni Mo Ti Co Fe AL Nb % % % % % % % % % % % % % […]
